Canon EOS R5 Deluxe Housing

200DL Underwater Housing for Canon EOS R5 Deluxe Version with Handles, Vacuum Pump, & USB-C Charging Bulkhead

Overview

The 200DL Underwater Housing for Canon EOS R5 is a professional-grade, durable housing designed for Canon's full-frame mirrorless camera. Suitable for scuba diving, snorkelling, surfing, pool use, and any aquatic activities, this housing ensures your camera remains fully protected and operational in the water.

Key Features

• Depth rating: 60 meters (200 feet)
• Strobe connector: Ikelite bulkhead with manual hotshoe
• Port mount: DL (Dry Lock system)
• USB-C charging and data transfer: First-of-its-kind bulkhead for charging and transferring photos without removing the camera from the housing
• Controls: Full camera control with some exceptions (e.g., Depth of Field preview, Multi-function lock, Multi-controller, and Mode button can be reassigned)
• Vacuum Pump: Allows pre-dive leak checks with built-in gauge
• Weight: 5.35 lb
• Dimensions: 229 x 184 x 152 mm (9 x 7.25 x 6 inches), excluding handles
• Rear O-ring: #0132.59
• Front O-ring: #0132.45

Lens Port Required

The housing requires a compatible DL lens port (sold separately) to ensure waterproof operation. Choose the correct port based on the lens you plan to use. Our DL-series ports offer excellent image quality and are some of the lightest available on the market.

Construction

Crafted from a specially formulated ABS-PC blend, the housing is lighter than aluminium yet exceptionally durable. The white colour helps keep the camera cool during extended use in sunny and warm environments.

Pre-Dive Checks & Leak Detection

The open-groove design allows you to see the rear O-ring seal, ensuring it is properly positioned and ready to form a waterproof seal once the housing is closed. The included vacuum pump allows for easy leak testing before diving.

Lens Support

Ikelite lens ports are lightweight yet sturdy, capable of withstanding rough conditions in the water. The housing supports a wide variety of lenses, with zoom and focus gears available for popular zoom lenses and select focus rings. Lens ports and zoom gears are sold separately.

Wi-Fi Transfer

Use the built-in Wi-Fi functionality of the Canon EOS R5 to transfer photos to a nearby device without removing the camera from the housing. This feature works above water within close proximity to the connected device.

Compatibility

This housing is specifically designed for the Canon EOS R5 and is not compatible with other camera models due to differences in lens and control placements. It does not support the use of add-on grips, battery grips, eyepieces, or other accessories.

In the Box

• 200DL Housing #71764
• Right Quick Release Handle #4077.02 (installed)
• (2) Trigger Extensions #4077.95 (installed)
• USB-C Charging & Data Transfer Bulkhead #46007 (installed)
• Vacuum Pump with Gauge #47011
• Spare Rear O-ring #0132.59
• Spare Front O-ring #0132.45
